Door Ram PDR200 – Battery-Powered Hydraulic Ram
A cordless hydraulic ram for trained response teams.
What it does
The PDR200 is a battery-powered, double-acting ram in the Pentheon range for approved professional access and rescue applications.
- 300 mm listed stroke.
- 71 kN listed spreading force across the full stroke.
- Bluetooth connectivity and a battery-powered format.
Who it is for
Trained response teams carrying out authorised operations within the manufacturer's approved applications.
How it works
The battery powers a hydraulic system that extends and retracts the ram. Hydraulic pressure produces linear force under operator control. Stroke, overall length and the rated application must be checked when selecting a ram.
What is included
- 1 × Door Ram PDR200
- 1 × Battery Charger PBCH3
- 2 × batteries
Before you order
Confirm the battery references and the PBCH3 charger's required power connection before ordering. Read the manufacturer's manual for approved applications and setup.
| Model | PDR200 |
|---|---|
| Max. working pressure | 720 / 72 (bar/MPa) / 10443 psi |
| Battery included | yes |
| Connectivity, mobile app | Bluetooth |
| Spreading force over full stroke | 71 / 7.2 (kN/t) / 15961 lbf |
| Spreading stroke | 300 mm / 11.8 in |
| Retracted length | 802 mm / 31.6 in |
| Extended length | 1102 mm / 43.4 in |
| Protection rating | IP57 |
| Directives | 2006/42/EC, 2014/30/EU |
| Weight (excl. battery) | 12.6 kg / 27.8 lb |
| Dimensions (AxBxC) | 180 x 802 x 196 mm / 7.1 x 31.6 x 7.7 in |
| Weight, ready for use (incl. battery) | 14.2 kg / 31.3 lb |
Training & suitability
For trained professional users only. Read the manufacturer's manual and follow its inspection, protective-equipment and maintenance requirements. Use only within the approved application and material ratings. Contact us to confirm the exact unit, accessories and documentation before ordering.
